Purpose:
non-contact temperature measurement.

Characteristics:

• Optical resolution up to 764 x 480 pixels
• Full temperature range: 450°C to 1,800°C
• Frame rates up to 1 kHz for fast processes
• Real-time average pixel output with 1ms setup time.

Responsible officer: Егоров Роман Игоревич

Purpose:
measuring the mass of samples.

Characteristics:

• Resolution 0.00001
• Maximum whole 92 g.
• Platform diameter 80 mm
• Connection to a computer using the RS-232 interface, the ability to monitor the mass of samples in real time

Responsible officer: Егоров Роман Игоревич

Purpose:
weighing components when preparing formulations.

Characteristics:

• maximum sample weight 420 g
• minimum sample weight 0.02 g
• resolution 0.001 g
• high accuracy class (II)

Responsible officer: Глушков Дмитрий Олегович

Purpose
: weighing components when preparing formulations.

Characteristics:

• maximum sample weight 220 g
• minimum sample weight 0.01 g
• resolution 0.0001 g
• special accuracy class (I).

Responsible officer: Глушков Дмитрий Олегович

Purpose:
construction of multi-channel measuring systems for input, output and processing of analog and digital information with a USB interface for connecting to a PC.

Characteristics:

• 16 channels
• ADC 14-bit, DAC 16-bit
• Voltage measurement subranges: ±10 V; ±2.5 V; ±0.6 V; ±0.15 V
• Maximum conversion frequency 200 kHz

Responsible officer: Егоров Роман Игоревич

Purpose:
creation of information and control systems for research and development work.

Characteristics:

• RAM capacity 32 MB
• Maximum data transfer rate 2 MB/s input + 2 MB/s output
• Frequency 60 MHz
• ADC board LTR-27 with 4 N-27T modules (for connecting thermocouples)

Responsible officer: Егоров Роман Игоревич

Purpose:
designed to measure the concentrations of individual components of a gas mixture.

Characteristics:

• CO 0-20% vol.
• CO 0-20000 ppm
• CO2 0-30% vol.
• CH 0-5% vol.
• NO 0-1000 ppm
• SO2 0-2000 ppm
• O2 0-21% vol.
• H2 0-40% vol.
• H2 0-5% vol.;
• Warm-up time 30 min.

Responsible officer: Егоров Роман Игоревич

Purpose:
Determination of electrical signal characteristics.

Characteristics:

• Analog bandwidth - 50 MHz
• Number of channels - 2
• Highest time sampling rate - 1 GSa/s
• The maximum recording length is 1 Mbit/s.

Responsible officer: Егоров Роман Игоревич

Purpose:
electrical signal characterization

Characteristics:

• Clock frequency – 30-118 MHz
• Resolution 1920x1216
• 2.35MPix
• Frame rate 41 fps.

Responsible officer: Егоров Роман Игоревич

Purpose:
macro optics for cameras with F-mount or C-mount.

Characteristics:

• Variable magnification 0.5x-3x
• F-mount or C-mount
• Working distance 12-35 cm

Responsible officer: Егоров Роман Игоревич

Purpose:
laser power measurement/pulse energy measurement.

Characteristics:

• Record every pulse of energy at up to 10 kHz
• Capture power and energy readings, averages and statistics, histograms and more using the StarLab app

Responsible officer: Егоров Роман Игоревич

Purpose:
laser power measurement/pulse energy measurement.

Characteristics:

• Maximum average power density 200 W/cm²
• Maximum pulse duration 20ms
• Maximum intensity 60 J/cm²
• Maximum average power 25 W;

Responsible officer: Егоров Роман Игоревич

Purpose:
laser power measurement/pulse energy measurement.

Characteristics:

• Maximum average power density 30 W/cm²
• Response time 0.2 s
• Maximum energy density (for <100 ns) N.D.
• Maximum energy density (at 2 ms) N.D.
• Maximum average power 3 W

Responsible officer: Егоров Роман Игоревич

Purpose:
video recording of fast processes. Impact of a drop with a surface.

Characteristics:

• maximum resolution 1280x800 pixels
• pixel size 20 µm x 20 µm
• minimum exposure time 1 µs
• video recording speed from 3,200 fps (1280x800) to 650,000 (64x8) fps
• minimum shooting speed 24 fps
• memory capacity 12 GB
• The duration of video recording depends on the resolution and recording speed, maximum 2.3 s at maximum shooting parameters

Responsible officer: Пискунов Максим Владимирович

Purpose:
video recording of fast processes. Impact of a drop with a surface.

Characteristics:

• maximum resolution 1280x1024 pixels
• pixel size 5.6 µm x 5.6 µm
• minimum exposure time 5 µs
• video recording speed from 915 fps (1280x1024) to 52,445 fps (128x8)
• minimum shooting speed 50 fps
• memory capacity 8 GB
• The duration of video recording depends on the resolution and recording speed, maximum 4.4 s at maximum shooting parameters

Responsible officer: Пискунов Максим Владимирович

Purpose:
analysis of flue gases released from gas/oil burners, engines or heating and energy appliances.

Characteristics:

• operating temperature: from +5 °C to +45 °C
• measuring range with electrochemical sensor (Long Life): 0…25% vol.
• measurement range with a paramagnetic sensor (: 25…100% vol.
• flue gas temperature measurement range using high-grade steel probe tube: 0…800 °C
• air temperature measurement range: 0…100°С
• Differential pressure measuring range: ±120 hPa
• Barometric pressure measurement range: 300-1200 hPa

Responsible officer: Антонов Дмитрий Владимирович

Purpose:
measurements of average (equivalent), exponentially averaged and peak levels of sound, infrasound and ultrasound; sound pressure levels (SPL) in octave and one-third octave frequency bands in the ranges of sound, infrasound and ultrasound; adjusted levels of vibration acceleration of general and local vibration and levels of vibration acceleration in octave and one-third octave frequency bands in the ranges of general and local vibration.

Characteristics:

• accuracy class 1 in accordance with GOST 17187-10, IEC 61672-1, group X
• frequency range of measurements with microphones MK265 and VMK205, MK233: 2…20000, 2…40000, G
• maximum deviation of the frequency response of the spectrum analyzer by electrical input in the range from 0.8 Hz to 40000 Hz, dB ±0.3
• reference frequency 1000 Hz
• reference sound level 94 dB

Responsible officer: Антонов Дмитрий Владимирович

Purpose:
accumulation, processing and transmission of information.

Characteristics:

• type: x64 based computer
• processor: Intel Core i9-10900F 2.8/5.2GHz, 10C/20T, 20Mb L3, DDR4-2933, TDP-65W, LGA1200, BOX [BX8070110900F]
• video card: PCI-E Palit GeForce RTX 2060 Super Dual 8192MB 256bit GDDR6 [NE6206S018P2-1160A-1] DVI HDMI DP
• memory: DIMM DDR4 32768MBx2 PC25600 3200MHz Corsair Vengeance LPX [CMK64GX4M2E3200C16] Black
